🔴- Adaptive cooling: Dynamically adjusts cooling levels based on real-time energy consumption to reduce component wear;
⚪- Sustainability-focused design: Compatible with solar photovoltaic and other renewable energy systems;
🟠- Energy independence and optimization: With an optional intelligent energy management system;
🔵- Enhanced safety mechanisms: The system is equipped with a variety of safety features.
Energy storage in distributed systems is an important technology applied in the energy field. It can effectively improve the reliability and stability of energy supply and provide flexible use of energy.
The air-cooling system dynamically adjusts cooling levels based on real-time energy consumption, reducing component wear and ensuring optimal performance and system longevity during periods of high demand
Compatible with solar PV and other renewable energy systems, supporting businesses committed to reducing their carbon footprint and achieving long-term sustainability goals
The system features an optional smart energy management system, which uses real-time data analysis and AI-driven energy optimization to enhance energy independence and reduce reliance on unstable grid connections
The system is equipped with multiple safety features, including fire suppression, thermal runaway prevention, and real-time diagnostics, ensuring continuous safe operation
| EK-ESS-DESA series distributed energy storage system | |||||
| Product number | EK-ESS-DESA1 | EK-ESS-DESA2 | EK-ESS-DESA3 | EK-ESS-DESA4 | EK-ESS-DESA5 |
| Number of battery cabinets | 1 | 2 | 3 | 4 | 5 |
| Rated energy | 215kWh | 430kWh | 645kWh | 860kWh | 1075kWh |
| rated power | 100KW | 200KW | 300KW | 400KW | 500KW |
| System efficiency | 90% | 90% | 90% | 90% | 90% |
| Grid-connected line system | 3W+N+PE | Grid voltage | 380(-15%~+10%) | Grid connection frequency (Hz) | 50(±2)/60(±2) |
| Power Factor | -0.9～+0.9 | Output harmonics | ≤3%(rated power) | cooling method | air cooling |
| Cycle life(times) | 80%DOD 6000 | Protection level | IP54 | Installation method | Outdoor, floor installation |
| weight | ≦2500KG | Certification | CE, ROHS, UN38.3/MSDS | ||
With the improvement of distributed energy level, the continuous improvement of performance and efficiency of various distributed power supply equipment, the cost of distributed power generation is also decreasing, and the application scope of distributed energy will continue to expand, covering a variety of places including office buildings, hotels, shops, restaurants, residences, schools, hospitals, welfare homes, sanatoriums, universities, stadiums, etc.
