EK-HBL48 Rack-Mounted Household Energy Storage System-

Products Categories

Choose Your Tagss

Contact Us

🔴- Modular design: Add more battery modules to the rack to expand capacity.
🟠- High efficiency: Advanced energy management for optimal charging/discharging performance.
🔴- Smart energy control: Supports grid-connected, off-grid, and hybrid solar system setups.
🟠- Enhanced safety: Equipped with overcharge, over-discharge, and temperature protection.
🔴- Durability: Withstands harsh environmental conditions.
🟠- Space-saving design: Compact rack-mounted structure for easy installation and maintenance.

Get Price

TAG: Energy Storage, energy storage device, Home, Lithium iron phosphate battery, rack-mounted, solar energy, Solar Panel, Solution, system

Descriptions:

The EK-HBL48 rack-mount home energy storage system is designed to provide a reliable and scalable energy storage solution for the home. The system features a compact rack-mount form factor that can be seamlessly integrated into the living environment.

The LiFePO4 battery energy storage module rack-mounted home energy storage unit is a solution for home energy storage that uses lithium iron phosphate (LiFePO4) battery technology and places the battery modules in a rack-mounted structure to achieve efficient and convenient home energy management.

EK-HBL4805

Parameters

Lithium Iron Phosphate Battery

Product Number	EK-HBL4850R	EK-HBL48100R
Battery Power	5.12kWh	10.24kWh
Battery Capacity	100Ah	200Ah
Rated Voltage	51.2Vdc
Rated Charge and Discharge Current	25A	50A
Maximum Charge and Discharge Current	50A	100A
Cycle Life	> 6000 times @80%DOD@25°C
Way of Communication	RS485/CAN
Display Screen	LCD/LED (optional)
Degree of Protection	IP20
Certified Product	CE/IEC/UN38.3/MSDS

Product Configuration

Item	Specifications and Models	Unit	Quantity
Battery system	Including 1 set of battery PACK, BMS system, more than 3000 cycles	SET	1
Photovoltaic storage inverter	Hybrid type,	PCS	1
	1) Photovoltaic input power: ≥5KW and photovoltaic voltage 125V~500V, with MPPT;
	2) AC voltage: 230V, frequency 50HZ/60HZ, output power 5KW;
	3) Battery voltage: 48V
	4) With LCD/LED display, with communication RS485;
	WIFI module, matching the optical storage integrated inverter for use		1
Power distribution system	/	SET	1
Accessories in the cabinet	/	SET	1
Solar panel	550W, monocrystalline silicon, single plane, N type	PIECE	6
Solar panel bracket	Suitable for the use of solar photovoltaic panels, the photovoltaic bracket is installed in the inclined roof	SET	6
Direct current cable	PV1-F 1*4mm²RED	M	12
Direct current cable	PV1-F 1*4mm²BLACK	M	12
Ground lead	6mm²Yellow green ground line	M	5
Junctor	MC4 male and female Junctors, including male and female Junctor pins.	SET	2
Wooden packaging	/	SET	1

What are the advantages of rack-mounted home energy storage units?

Energy storage: Rack-mounted home energy storage units typically contain high-capacity battery packs such as lithium-ion batteries, which can be used to store excess solar or grid power. This helps smooth power delivery and provide backup power.
Solar integration: These systems are usually designed to integrate with solar photovoltaic systems and can store solar energy captured during the day to provide power at night or on cloudy days.
Grid connection: Rack-mounted home energy storage units are usually connected to the power grid and can sell excess power back to the grid when needed or take power from the grid to supply power shortages.
Intelligent control: These systems are usually equipped with intelligent power management systems that monitor household power demand, power prices and solar power generation, and automatically decide when to charge or discharge.
Backup power: Such systems can be used as backup power to deal with power outages or emergencies.
Energy savings and cost reduction: Rack-mounted home energy storage units allow households to make full use of renewable energy and use stored power when power prices are high, thereby reducing electricity bills.
Environmental protection: The use of solar energy and energy storage technology can reduce the demand for fossil fuels and reduce greenhouse gas emissions, which helps protect the environment.

Summarize

These rack-mounted energy storage units can be integrated with a home solar battery system to store the solar energy collected during the day in the battery for use at night or on cloudy days. This helps increase self-sufficiency, stabilize power supply and reduce household electricity bills.

EK-HBL48 Rack-Mounted Household Energy Storage System
