🔴Space-saving design: Wall-mounted structure allows for efficient use of space, ideal for indoor installation.
🔵High efficiency: Advanced energy management ensures optimal charging and discharging performance.
🟣Smart energy control: Seamlessly integrates with solar panels and grid systems, providing off-grid, grid-connected and hybrid configurations.
🟠Safety and security: Multi-level safety protection, including over-charging, over-discharging and temperature control.

Get Price

TAG: EK-HSH48, energy management, Energy Storage, home use, inverter, Lithium battery

Descriptions:

In today's era of growing energy demand and increasing emphasis on sustainable development, the emergence of EK's new generation of household energy storage and inverter systems has brought a new solution to home energy management.



Features:

  • 2MPPT Output for max 15kW PV Array
  • AC / DC Coupling
  • IP65 rated for indoor & outdoor installation
  • Built-in generator port
  • 10 units in parallel
  • Online monitoring/app
  • Color LCD touch screen

Specifications:

  • Max. DC Input Power for Single MPPT: 6000W/6000W
  • Max. PV Input Power: 15000W
  • Max. PV Power Delivered to Battery & AC Outputs: 12000W
  • DC Input Voltage Range: 100V-600V
  • Nominal DC Input Voltage: 360V
  • Full Power MPPT Voltage Range: 210V-500V
  • Max. DC Input Current: 25A/25A
  • MPPT Number/(Strings per MPPT): 2/2



EK HSH48 5

Output/Input AC (Grid)

  • Continuous AC Power to Grid: 10000W (240V)
  • Continuous AC Power to Load with Grid or Generator: 21000W (240V)
  • Nominal Output Voltage: 120V/240V
  • Max. Continuous AC Current: 41.6A @ 240V
  • Nominal AC Frequency: 50Hz/60Hz

Output AC (Off-Grid)

  • Max. Output Power: 10000W (240V)
  • Nominal Output Voltage: 120V/240V
  • Nominal Output Frequency: 50Hz/60hZ
  • Nominal Output Current: 41.6A @ 240V
  • Peak Power: 20kW 500ms

Battery Parameters

  • Compatible Battery Type: LFP-5, LFP-10 MAX,etc..
  • Nominal Battery Voltage: 48V
  • Battery Voltage Range: 40V-60V
  • Maximum Charging/Discharging Current: 210A
  • Maximum Charging/Discharging Power: 10000W

EK HSH48 6

Conclusion:

If you're looking for a complete energy storage inverter system for your entire home, you might want to check out the EK-HSH48. This energy storage inverter works with multiple battery models to provide up to 10kW of backup power for your entire house. The inverter also features a 90A AC pass-through, allowing you to connect to the grid or a generator when needed. The EK-HSH48 inverters feature 2 MPPT outputs that can support solar arrays up to 13 kW or 15 kW, depending on the model. They also come with a built-in rapid shutdown transmitter and push button, as well as integrated AC and DC circuit breakers for easy installation and safety. You can monitor and control your system from anywhere using the online monitoring app. The EK-HSH48 is the ultimate all-in-one solution for your home energy needs.
