🔴- Mobility: portable solar solution.
🔵- Scalable: easily expandable to other containers.
⚪- Energy-saving and environmentally friendly: using solar energy as the main energy source.
🟠- Ready-to-use: customized 20-foot container.
While increasing the power generation power, this module maximizes container transportation efficiency through innovative layout design, significantly reduces logistics costs, and injects new vitality into the overall economic improvement of photovoltaic projects.
PV power |
Wind power |
Power grid side |
Industry and commerce |
Reduced Cost
● Integrated energy storage system, easily on the installation, operation and maintenance;
●Large module design, stronger than traditional energy sources Solution 50%
Safty
● Multiple balancing measures to ensure consistent battery life cycle;
● Integrated gas and water fire extinguishing device to ensure system safety under extreme circum-stances.
Increased Efficiency
● Based on the 1500V platform design, the DC side efficiency can reach 93%；
● As high as C4H the anti-corrosion level of the outter box, service life over 15 years.
Smart
●Multi-dimensional battery status analysis enables rapid analysis and location of system faults;
●Unattended cloud real-time monitoring.
| Mode | EKSPV 3.44 | EKSPV 3.85 | EKSPV 5 |
| Rated Capacity | 3.44 MWh | 3.85 MWh | 5.016 MWh |
| Rated Power | 1.725 MW | 2 MW | 2.5 MW |
| Rated Voltage | 1228.8V | 1228.8V | 1331.2V |
| Voltage Range | 1075.2V ~ 1382.4V | 1075.2V ~ 1382.4V | 1164.8V ~ 1497.6V |
| Battery Type | LFP | ||
| Soc Estimation Accuracy | ≤5% | ||
| Self-Discharge Rate Month | ≤3% | ||
| IP Protection Level | IP54 | ||
| Weight (kg) | 33,000 | 36,000 | 45,000 |
| Cooling Type | Liquid Cooling | ||
| Noise | <65 dB ( 1m away from the System ) | ||
| Communication Interface | Wired: LAN, CAN, RS485 | ||
| Communication Protocol | Modbus Tcp | ||
| System Certification | IEC/EN 62477, NFPA855, IEC/EN 62619, IEC/EN 60730, IEC/EN 63056, UL 1973, UL 9540A | ||
