EK-BP100Ah Energy Storage Battery Pack

Descriptions:

The battery pack is the core component of the battery energy storage system, which is composed of multiple battery cells connected in series or in parallel. The capacity of the battery pack determines the amount of electrical energy that the energy storage system can store. Currently, the commonly used battery types include lead-acid batteries, lithium-ion batteries, sodium-sulfur batteries, etc.

Product name：EK-BP100Ah Rack-mounted energy storage battery pack

1. Product model：51.2V100Ah
2. Cell type：LiFePO4
3. Advantage：The capacity of a single battery pack is about 5 kilowatt-hours. Multiple battery packs can be connected in parallel to expand the power.

Battery parameters

• Rated voltage (V) 51.2V
• Rated capacity(Ah) [email protected]
• Minimum capacity(Ah) [email protected]
• Rated power (KWh) 5.1KWh
• Cycle life ≥3000 Cycles @0.3C/0.3C
• Combination mode 1P16S

Charging parameters

• Charging voltage(V) 58.4V
• Charging current(A) 30A(Recommend )
• Max charging current(A) 100A
• Peak charging current(A) 100A
• Factory voltage: 52V-52.8V(70%SOC)
• Communication interface RS485/CAN/232

Discharge parameters

• Discharge cut-off voltage(A) 41.6V
• Rated discharge current(A) 30A(Recommended)
• Max discharge current(A) 100A

Temperature parameters

• Charging temperature (℃) 0℃ to 55℃
• Discharging temperature(℃) -20℃ to 60℃
• Storage temperature(℃) 0℃ to 45℃

Battery box

1. Color/Material White/Sheet metal
2. Dimensions 482(L)*373(W)*177(H)mm
3. Weight 45Kg
4. IP grade IP55
5. Installation method Rack-mounted
6. Certification MSDS、UN38.3、CE

Conclusion:

With our proactive actions and hard work, currently our EK-BP100Ah has covered users in North and South America, Southeast Asian countries, Australia and European countries.
